MANUAL PC-200
Ver. 2.12.xx/10/22/2010-UK
Page 46 (61)
10 I/O-list, Signal table
Upprättad av
Prepared by
Datum - Date
Dokument Nr
Document No.
Rev
Contaktperson
yy-mm-dd
A
Referens / Object:
Tillhör referens - File/Reference
Company / Station name
PC-200 - Programversion: 2.12.1
I/O no
Signal type
Signal function
Notes
DOI
17//18
Start/Stopp P1
NO
DO2
19/20
Start/Stopp P2
NO
DO3
21/22
Start/Stopp P3
NO
DO4
23/24
Mixer
NO
DO5
25/26
Not acknowledged alarms
NC
DO6
27
Attendance alarm
NO
DO7
28
Modem control
NO
.
DI 1
29
P1 Not in Auto
NC
Most times NC
DI 2
30
P1 Motor protector
NO
DI 3
31
P2 Not in Auto o
NC
Most times NC
DI 4
32
P2 Motor protector
NO
DI 5
33
P3 Not in Auto
NC
Most times NC
D I6
34
P3 Motor protector
NO
DI 7
35
Low level
NO
DI 8
36
High level / Overflow
NO
DI 9
8
External blocking / Overflow
NO
DI 10
12
Attendance check
NO
L1
1
Voltage phase L1
L2
2
Voltage phase L2
L3
3
Voltage phase L3
N
4
Neutral for voltage and current
I1
5
Current input P1
I2
6
Current input P2
I3
7
Current input P3
T1
9
P1 Temp. protection
NC
T2
10
P3 Temp. protection
NC
T3
11
P3 Temp. protection
NC
CI
37
Pulse input (Counter)
--
AI 1
13
Analogue In (0/4-20 mA)
Analogue input
AI2
2
Analogue In (0/4-20 mA)
Free choice Analogue input
