32
VAPOR-LOGIC
®
VERSION 6 INSTALLATION AND OPERATION MANUAL
INSTALLATION
Step 2 – Setup
Table 30-1:
Settings menu (continued)
Menu item Default value
Minimum
value
Maximum value Units Notes
Aquastat -- -- -- --
Aquastat Feature Enabled -- -- --
The minimum aquastat setting prevents tank water
freezing. Higher settings keep tank water warm,
reducing time required to bring water to boiling
after a call for humidity.
Aquastat Setpoint
50 40 180 °F
10 4 82 °C
Service Interval -- -- -- --
Service Interval Model-specific 0 2,200,000 lbs
Select amount of water to be converted to steam
or hours that humidifier runs before service
interval is reached.
Service Interval Model-specific -- 1,000,000 kg
Fill Fault Time-Out -- -- -- --
Fill Fault Time-Out 40 10 250 Minutes Amount of fill time before an alert will occur.
Drain Tempering -- -- -- --
Drain Tempering Feature Enabled Disabled Enabled --
Enable drain tempering to keep drain water below
140°F (60°C)
Drain Valve
Normally
Closed
Normally
Closed
Normally
Open
--
Changing drain valve action requires changing
the drain valve. Not all options available for all
models.
Test
Test Outputs -- -- -- --
Choose “Start” to turn on the output for a few
seconds. Choose “Back” if you do not want to
test the output at this time. Once the test starts it
cannot be cancelled. After the test the mode will
change to Standby.
Fill Valve 5 5 5 Seconds
Pulse Fill Valve(s) 5 5 5 Seconds
Drain Valve 10 10 10 Seconds
Fan Control 5 5 5 Seconds
Ignition Module 1 or 2 8 8 8 Seconds
Blower Speed Control 10 10 10 Seconds
Dry Contact 1 or 2 5 5 5 Seconds
Test Run -- -- -- --
Simulate a demand for steam production when
there isn’t one so that the humidifier can produce
steam for a specific amount of time. Humidifier
will return to Standby mode.
Test Run Percent 100 0 100 %
Test Run Time 5 1 30 Minutes
Start/Stop Test Run -- Start Stop --
Communications
IP Addressing -- -- -- --
Automatically obtain an IP address from a network
server or assign a static IP address
IP Address 192.168.1.195 0.0.0.0 255.255.255.255 --
IP Mask 255.255.255.0 0.0.0.0 255.255.255.255 --
Gateway 192.168.1.1 0.0.0.0 255.255.255.255 --
Auto Obtain Address No -- -- --
Use the touchscreen display to access this menu
item. This item is not available when using the
Web interface.
