40
VAPOR-LOGIC
®
VERSION 6 INSTALLATION AND OPERATION MANUAL
Status screen
Table 41-1:
Status screen (continued)
Menu item Default value
Minimum
value
Maximum
value
Units Notes
Board voltage 24 0 30 VAC
Board temp -- 0 200 °F
High probe signal -- 0 14000 counts
High water probe -- Water No water --
Mid probe signal -- 0 14000 counts
Mid water probe -- Water No water --
Low probe signal -- 0 14000 counts
Low water probe -- Water No water --
Airflow switch -- Flow No flow --
Interlock switch -- Open Closed --
Water until
drain/flush
-- -- 2,200,000 lbs
Displays amount of water to be converted to steam before
automatic drain sequence (ADS) can begin
-- -- 1,000,000 kg
Water until service
-- -- 2,200,000 lbs
Displays amount of water to be converted to steam before next
recommended maintenance service
-- -- 1,000,000 kg
Blower 1 tach -- 0 7000 rpm Displays rotation speed of Blower 1
Blower 2 tach -- 0 7000 rpm Displays rotation speed of Blower 2
Gas valve 1 -- Open Closed --
Gas valve 2 -- Open Closed --
OPERATION
