Ducati Hyperstrada User Manual

Light control
Headlight control
This function allows you to reduce current
consumption from the battery, by automatically
managing headlight switching-off.
At Key-On, the high beam and low beam lights are
off. As soon as engine is started, low beams will be
automatically turned on; from now on, "standard"
operation will be active, i.e. whenever button (3) is
pressed, it will be possible to switch from low beams
to high beams with button (3) in position (V) or
"FLASH" with button (3) in position (O). If engine is not
started upon Key-On, lights can nevertheless be
activated by pressing LH high/low beam switch:
button (3) in position (V).
When button is pressed the "first" time, low beams
will be turned on; from now on this button can be
used to turn high beams on or off: if engine is not
started within 60 seconds, low and high beams will
be turned Off.
3
O
V
Fig. 61
If the headlight was turned on before starting the
engine with the procedure described above, the
headlight turns off automatically when starting the
vehicle and will turn on again when the engine has
been completely started.
110

Ducati Hyperstrada Specifications

General

Transmission	6-speed
Frame	Tubular steel Trellis frame
Exhaust	2-1-2 system with catalytic converter and 2 lambda probes
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive linkage with adjustable Sachs monoshock
Front Brake	2 x 320 mm semi-floating discs, radially mounted Brembo monobloc 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Fuel Tank Capacity	16 liters (4.2 US gal)
Fuel Injection	Electronic fuel injection, 53 mm throttle bodies
