Ducati Hyperstrada User Manual

Controls
Position of motorcycle controls
Warning
This section shows the position and function of
the controls used to ride the motorcycle. Be sure to
read this information carefully before you use the
controls.
1) Instrument Panel.
2) Key-operated ignition switch and steering lock.
3) LH switch.
4) Clutch lever.
5) Rear brake pedal.
6) RH switch.
7) Throttle twistgrip.
8) Front brake lever.
9) Gear change pedal.
13
2
5
6
8
7
4
9
Fig. 70
125

Ducati Hyperstrada Specifications

General

Transmission	6-speed
Frame	Tubular steel Trellis frame
Exhaust	2-1-2 system with catalytic converter and 2 lambda probes
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive linkage with adjustable Sachs monoshock
Front Brake	2 x 320 mm semi-floating discs, radially mounted Brembo monobloc 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Fuel Tank Capacity	16 liters (4.2 US gal)
Fuel Injection	Electronic fuel injection, 53 mm throttle bodies
