LCD - Main functions
Warning
Operate on instrument panel only when the
motorcycle is stopped. Do not operate on instrument
panel while you are riding the motorcycle under no
circumstances.
Data displayed on the main screen are as follows:
1) Engine RPM Indicator;
2) Vehicle Speed Indicator;
3) MENU 1 (Odometer, Trip 1, Trip 2, Trip Fuel,
Average Consumption, Instantaneous Consumption,
Average Speed and Trip Time) – UP-MAP Menu and
Riding Mode Set-up Menu;
4) MENU 2 (Engine Coolant Temperature, Ambient
Air Temperature and Clock);
5) Name of set Riding Mode;
6) Riding Mode DTC and ABS settings.
2
1
45
3
6
Fig. 5
Important
Do not ride the motorcycle if temperature
reaches the max. value as engine could suffer severe
damage.
