Ducati Hyperstrada User Manual

Engine
Longitudinal 90º “L” twin cylinder, four-stroke.
Bore, mm:
88.
Stroke, mm:
67.5.
Total displacement, cu. cm:
821.1.
Compression ratio:
12.8±0.5:1
Max crankshaft power (95/1/EC), kW/HP:
81 kW/110 HP at 9,250
rpm
Max torque at crankshaft (95/1/EC):
9.1 kgm/89 Nm at 7,750
rpm
Maximum rpm:
10,500.
Important
Do not exceed the specified rpm limits in any
running conditions.
205

Ducati Hyperstrada Specifications

General

Transmission	6-speed
Frame	Tubular steel Trellis frame
Exhaust	2-1-2 system with catalytic converter and 2 lambda probes
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive linkage with adjustable Sachs monoshock
Front Brake	2 x 320 mm semi-floating discs, radially mounted Brembo monobloc 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Fuel Tank Capacity	16 liters (4.2 US gal)
Fuel Injection	Electronic fuel injection, 53 mm throttle bodies
