Ducati Hyperstrada User Manual

Warning
If the rear sprocket needs replacing, contact a
Ducati Dealer or authorised Service Centre.
If improperly replaced, this component could
seriously endanger your safety, as well as the
passenger one, and cause irreparable damage to your
motorcycle.
Frame
Steel tube trellis frame.
Die-cast aluminum rear subframe.
Steering head angle: 25.5°.
Wheels
Front
10-spoke, light-alloy rims.
Size: MT3.50x17”
Rear
10-spoke, light-alloy rims.
Size: MT5.50x17”
Both wheels have removable axles.
Tyres
Front
Tubeless, radial tyre.
Size: 120/70-ZR17
Rear
Tubeless, radial tyre.
Size: 180/55-ZR17
Suspensions
Front
Hydraulic upside-down fork
Stanchion diameter:
43 mm.
Wheel travel:
150 mm (standard seat);
130 mm (low seat);
Rear
Progressive. The shock absorber is adjustable for
rebound and spring preload. At the bottom pivot point
it is connected to a die-cast aluminium single-sided
swingarm. The whole system gives the bike excellent
stability.
Shock absorber stroke:
61.5 mm (standard seat);
55.5 mm (low seat).
Rear wheel travel:
150 mm (standard seat);
209

Ducati Hyperstrada Specifications

General

Transmission	6-speed
Frame	Tubular steel Trellis frame
Exhaust	2-1-2 system with catalytic converter and 2 lambda probes
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive linkage with adjustable Sachs monoshock
Front Brake	2 x 320 mm semi-floating discs, radially mounted Brembo monobloc 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Fuel Tank Capacity	16 liters (4.2 US gal)
Fuel Injection	Electronic fuel injection, 53 mm throttle bodies
