Clutch control free play adjustment
Warning
A wrong adjustment can seriously affect the
clutch operation and life.
When worn, clutch stretches clutch cable.
Always check clutch free play, with the engine cold,
before riding the vehicle.
When operating clutch, you must clearly feel the shift
from a very low force required to pull the lever to quite
a stronger one (working force).
Free play corresponds to the lever stroke at which
resistance force is kept at a very low level.
Operate lever so as to cover its free play, and make
sure that distance "A" is between 3 and 4 mm.
To restore recommended free play value, make sure
that free play is not equal to zero. Work on primary
adjuster (2) close to clutch control.
2
A
Fig. 75
129

Ducati Hyperstrada Specifications

General

Transmission	6-speed
Frame	Tubular steel Trellis frame
Exhaust	2-1-2 system with catalytic converter and 2 lambda probes
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive linkage with adjustable Sachs monoshock
Front Brake	2 x 320 mm semi-floating discs, radially mounted Brembo monobloc 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Fuel Tank Capacity	16 liters (4.2 US gal)
Fuel Injection	Electronic fuel injection, 53 mm throttle bodies
