Ducati Hyperstrada User Manual

49) Left-hand switch
50) Front left turn indicator
51) Horn
52) Air temperature sensor
53) Heated grips
54) Instrument panel
55) Rear stop
56) Front stop
57) Front right turn indicator
58) Headlight
59) Serial line
60) Immobilizer
61) Rider power outlet
62) Passenger power outlet
Wire colour coding
B Blue
W White
V Violet
Bk Black
Y Yellow
R Red
Lb Light blue
Gr Grey
G Green
Bn Brown
O Orange
P Pink
Note
The electric system wiring diagram is at the end
of this manual.
