Ducati MULTISTRADA V4 User Manual

ABS
LEVEL
RIDING MODE OPERATION CHARACTERISTIC DEFAULT
2 SPORT This level is designed for road use, with
good grip conditions. ABS in this level
controls both wheels, system creates
pressure also at the rear calliper when
the rider uses only the front brake
(combined braking), and the cornering
function and  control function
are active. This calibration gives priority
to the braking power while ensuring a
good compromise between 
 and stability.
It is the default level for the
"SPORT" Riding Mode
3 SAFE & STABLE This level is designed for use in any rid‐
ing conditions to provide a safe and
consistent braking action. ABS in this
level controls both wheels, system cre‐
ates pressure also at the rear calliper
when the rider uses only the front brake
(combined braking), and the cornering
function and  control function
are active.
It is the default level for the
"TOURING" and "URBAN"
Riding modes.
140

Ducati MULTISTRADA V4 Specifications

General

Displacement	1, 158 cc
Power	170 hp (125 kW) @ 10, 500 rpm
Torque	125 Nm (92 lb-ft) @ 8, 750 rpm
Transmission	6-speed with Ducati Quick Shift (DQS) up/down
Bore x Stroke	83 mm x 53.5 mm
Compression Ratio	14:1
Front Wheel Travel	170 mm (6.7 in)
Rear Wheel Travel	180 mm (7.1 in)
Front Tire	120/70 ZR19
Rear Tire	170/60 ZR17
Wheelbase	1, 567 mm (61.7 in)
Dry Weight	215 kg (474 lb)
Curb Weight	240 kg (529 lb)
Fuel Capacity	22 l (5.8 US gal)
Engine Type	V4 Granturismo, 4-cylinder, liquid-cooled
Fuel Injection	Electronic fuel injection system, Øeq 46 mm throttle bodies
Exhaust	Single stainless steel muffler with catalytic converter and 2 lambda probes
Final Drive	Chain
Frame	Aluminum monocoque
Front Brake	2 x Ø 330 mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	Ø 265 mm disc, 2-piston caliper
Seat Height	Adjustable 840-860 mm (33.1-33.9 in)
Safety Equipment	Cornering ABS, Ducati Traction Control
Standard Equipment	Cruise Control, TFT color display
