Side stand

Place the motorcycle on the side stand only
when you are not going to use it for  periods of
time. Before lowering the side stand, make sure that
the bearing  is hard and flat.
Do not park on  or pebbled ground or on asphalt
melted by the sun, etc. or else the motorcycle may
fall over. When parking downhill, always position the
motorcycle with the rear wheel facing downhill.
To pull down the side stand, hold the motorcycle
handlebar with both hands and push down on the
side stand (1) with your foot until it is fully extended.
Tilt the motorcycle until the side stand is resting on
the ground.
To move the side stand to its rest position (horizontal
position), lean the motorcycle to the right while
 the thrust arm (1) with your foot.
To ensure trouble-free operation of the side stand
joint, thoroughly clean it and then use SHELL
Alvania R3 grease to lubricate all friction points.

Do not sit on the motorcycle when it is
 on the side stand.
Note
Check for proper operation of the stand
mechanism (two springs, one into the other) and the
safety sensor (2) at regular intervals.
Note
It is possible to  the engine with stand
unfolded and gearbox in neutral.
2
1
Fig 20
37

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ducati MULTISTRADA V4 and is the answer not in the manual?

Ducati MULTISTRADA V4 Specifications

General IconGeneral
Displacement1, 158 cc
Power170 hp (125 kW) @ 10, 500 rpm
Torque125 Nm (92 lb-ft) @ 8, 750 rpm
Transmission6-speed with Ducati Quick Shift (DQS) up/down
Bore x Stroke83 mm x 53.5 mm
Compression Ratio14:1
Front Wheel Travel170 mm (6.7 in)
Rear Wheel Travel180 mm (7.1 in)
Front Tire120/70 ZR19
Rear Tire170/60 ZR17
Wheelbase1, 567 mm (61.7 in)
Dry Weight215 kg (474 lb)
Curb Weight240 kg (529 lb)
Fuel Capacity22 l (5.8 US gal)
Engine TypeV4 Granturismo, 4-cylinder, liquid-cooled
Fuel InjectionElectronic fuel injection system, Øeq 46 mm throttle bodies
ExhaustSingle stainless steel muffler with catalytic converter and 2 lambda probes
Final DriveChain
FrameAluminum monocoque
Front Brake2 x Ø 330 mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear BrakeØ 265 mm disc, 2-piston caliper
Seat HeightAdjustable 840-860 mm (33.1-33.9 in)
Safety EquipmentCornering ABS, Ducati Traction Control
Standard EquipmentCruise Control, TFT color display
