Ducati MULTISTRADA V4 User Manual

Engine
Ducati V4 Granturismo: V4 90°, counter-rotating
 4 valves per cylinder, liquid cooling
Timing system with spring valve return system.
Bore: 83 mm (3.27 in).
Stroke: 53.5 mm (2.09 in).
Total displacement: 1158 cu. cm (70.66 cu in).
Compression ratio: (14±0.5):1.
Maximum power at
 (EU) Regulation no.
134/2014, Annex X, kW/HP:
125 kW / 170.0 HP at 10,500 rpm
Max. power at  Regulation (EU) no.
134/2014 Annex X, kW/HP, for France/Belgium
version only:
84 kW / 114.2 HP at 7,000 rpm
Maximum torque at
 (EU) Regulation no.
134/2014 Annex X:
125.0 Nm / 12.7 kgm at 8,750 rpm
Max. torque at
 Regulation (EU) no.
134/2014 Annex X, for France/Belgium version only:
114 Nm / 11.6 kgm at 7,000 rpm
Maximum rpm: 11,
500 rpm.
Note
The engine control unit disables the 2 rear bank
cylinders when engine is idling and the

twistgrip is fully released. This disabling is only
implemented when some conditions are verified and
namely depending on the engine temperature, gear
engaged and clutch lever position (that must be
completely pulled unless gear is in Neutral). This
strategy ensures advantages in terms of fuel
economy and rider's  because of less heat.

Do not exceed the specified rpm limits in any
running conditions.
Note
The indicated power/torque values have been
measured with a static test bench according to type-
approval standards and match with the data
detected during type-approval process; they are
indicated in the vehicle registration document.
Lubrication
One trochoid oil delivery pump with integrated by-
pass valve and two trochoid scavenge pumps.
249

Ducati MULTISTRADA V4 Specifications

General

Displacement	1, 158 cc
Power	170 hp (125 kW) @ 10, 500 rpm
Torque	125 Nm (92 lb-ft) @ 8, 750 rpm
Transmission	6-speed with Ducati Quick Shift (DQS) up/down
Bore x Stroke	83 mm x 53.5 mm
Compression Ratio	14:1
Front Wheel Travel	170 mm (6.7 in)
Rear Wheel Travel	180 mm (7.1 in)
Front Tire	120/70 ZR19
Rear Tire	170/60 ZR17
Wheelbase	1, 567 mm (61.7 in)
Dry Weight	215 kg (474 lb)
Curb Weight	240 kg (529 lb)
Fuel Capacity	22 l (5.8 US gal)
Engine Type	V4 Granturismo, 4-cylinder, liquid-cooled
Fuel Injection	Electronic fuel injection system, Øeq 46 mm throttle bodies
Exhaust	Single stainless steel muffler with catalytic converter and 2 lambda probes
Final Drive	Chain
Frame	Aluminum monocoque
Front Brake	2 x Ø 330 mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	Ø 265 mm disc, 2-piston caliper
Seat Height	Adjustable 840-860 mm (33.1-33.9 in)
Safety Equipment	Cornering ABS, Ducati Traction Control
Standard Equipment	Cruise Control, TFT color display
