Restoring motorcycle operation via
the PIN Code
In case of key acknowledgement system or key
malfunction, the instrument panel allows the user to
enter his/her own PIN code to temporarily restore
motorcycle operation.
If the PIN code has been activated via the "PIN Code"
function in the  menu page 161, the
instrument panel displays "PIN Code" and next to it
the spaces for the four digits of the PIN to be
entered.
Entering the code:
The 2 arrows above and below the digit indicate
that the number can be changed from 0 to 9
using  (1) and (2).
Press ENTER (3) to confirm and move on to the
following digit.
Repeat the procedure until entering all 4 digits.
Once the  digit is set, press ENTER and the
instrument panel behaviour will be as follows:
if there is a problem during the PIN check, the
instrument panel displays an error for 2 seconds
and then passes to the main screen;
PIN Code
0
---
Fig 61
1
3
2
Fig 62
76

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ducati MULTISTRADA V4 and is the answer not in the manual?

Ducati MULTISTRADA V4 Specifications

General IconGeneral
Displacement1, 158 cc
Power170 hp (125 kW) @ 10, 500 rpm
Torque125 Nm (92 lb-ft) @ 8, 750 rpm
Transmission6-speed with Ducati Quick Shift (DQS) up/down
Bore x Stroke83 mm x 53.5 mm
Compression Ratio14:1
Front Wheel Travel170 mm (6.7 in)
Rear Wheel Travel180 mm (7.1 in)
Front Tire120/70 ZR19
Rear Tire170/60 ZR17
Wheelbase1, 567 mm (61.7 in)
Dry Weight215 kg (474 lb)
Curb Weight240 kg (529 lb)
Fuel Capacity22 l (5.8 US gal)
Engine TypeV4 Granturismo, 4-cylinder, liquid-cooled
Fuel InjectionElectronic fuel injection system, Øeq 46 mm throttle bodies
ExhaustSingle stainless steel muffler with catalytic converter and 2 lambda probes
Final DriveChain
FrameAluminum monocoque
Front Brake2 x Ø 330 mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear BrakeØ 265 mm disc, 2-piston caliper
Seat HeightAdjustable 840-860 mm (33.1-33.9 in)
Safety EquipmentCornering ABS, Ducati Traction Control
Standard EquipmentCruise Control, TFT color display
