Ducati MULTISTRADA V4 - Seat Lock and Seat Removal

Seat lock
Working lock with key (1) you can remove the
passenger seat, to reach the tool box, and the rider
seat, to reach the  and other devices.
Removing the seats
 the key into the catch (1) and turn it clockwise
until the passenger seat latch disengages with an
audible click.
Carefully  the passenger seat (2) at the rear.
Remove the passenger seat (2).
1
OPEN
Fig 8
2
Fig 9
30
