Ducati MULTISTRADA V4 User Manual

 menu - PIN Code
This function allows the user to activate or modify
the PIN Code.
●
Use  (1) and (2) from the Interactive
Menu to select the  menu item and press
ENTER (3).
●
Select the "PIN Code" item and press ENTER.
The PIN Code is initially not present in the
motorcycle and must be activated by the user by
entering the 4-digit PIN in the instrument panel,
otherwise the motorcycle cannot be 
temporarily in the case of a malfunction.
In order to temporarily  the motorcycle in case
of malfunction, please refer to the procedure called
Restoring motorcycle operation via the PIN Code.
If the PIN Code has never been activated, this menu
will include New PIN item to activate it. While if the
PIN Code has already been activated, this menu will
include Modify PIN item, which allows modifying the
already stored PIN.

The PIN Code must be activated and stored by
the vehicle owner. If a PIN Code is already set, please
contact your Ducati authorised dealer to reset it. The
Ducati authorised dealer may ask you to
demonstrate that you are the owner of the
motorcycle.
1
3
2
Fig 139
161

Ducati MULTISTRADA V4 Specifications

General

Displacement	1, 158 cc
Power	170 hp (125 kW) @ 10, 500 rpm
Torque	125 Nm (92 lb-ft) @ 8, 750 rpm
Transmission	6-speed with Ducati Quick Shift (DQS) up/down
Bore x Stroke	83 mm x 53.5 mm
Compression Ratio	14:1
Front Wheel Travel	170 mm (6.7 in)
Rear Wheel Travel	180 mm (7.1 in)
Front Tire	120/70 ZR19
Rear Tire	170/60 ZR17
Wheelbase	1, 567 mm (61.7 in)
Dry Weight	215 kg (474 lb)
Curb Weight	240 kg (529 lb)
Fuel Capacity	22 l (5.8 US gal)
Engine Type	V4 Granturismo, 4-cylinder, liquid-cooled
Fuel Injection	Electronic fuel injection system, Øeq 46 mm throttle bodies
Exhaust	Single stainless steel muffler with catalytic converter and 2 lambda probes
Final Drive	Chain
Frame	Aluminum monocoque
Front Brake	2 x Ø 330 mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	Ø 265 mm disc, 2-piston caliper
Seat Height	Adjustable 840-860 mm (33.1-33.9 in)
Safety Equipment	Cornering ABS, Ducati Traction Control
Standard Equipment	Cruise Control, TFT color display
