Ducati MULTISTRADA V4 User Manual

Refer to the paragraphs "Tubeless Tyres" in the
"Main use and maintenance operations" section and
"Tyres" in the "Technical specifications" section.

If you install the side panniers (available on
request from Ducati  service),  out luggage
and accessories according to their weight and
arrange them in the side panniers to evenly
distribute the weight. Close the side panniers with
the relevant key locks.
Dangerous products - warnings
Used engine oil

Prolonged or repeated contact with used
engine oil may cause skin cancer. If working with
engine oil on a daily basis, we recommend washing
your hands thoroughly with soap immediately
 Keep away from children.
Brake dust
Never clean the brake assembly using compressed
air or a dry brush.
Brake fluid

Spilling brake fluid onto plastic, rubber or
painted  of the motorcycle may cause damages.
Protect these  with a clean shop cloth before
proceeding to service the system. Keep away from
children.

The fluid used in the brake system is corrosive.
In the event of accidental contact with eyes or skin,
wash the  area with abundant running water.
Coolant
Engine coolant contains ethylene glycol, which may
ignite under  conditions, producing
invisible flames. Although the flames from burning
ethylene glycol are not visible, they are still capable
of causing severe burns.

Take care not to spill engine coolant on the
exhaust system or engine 
These  may be hot and ignite the coolant,
which will subsequently burn with invisible flames.
Coolant (ethylene glycol) is irritant and poisonous
when ingested. Keep away from children. Never
22

Ducati MULTISTRADA V4 Specifications

General

Displacement	1, 158 cc
Power	170 hp (125 kW) @ 10, 500 rpm
Torque	125 Nm (92 lb-ft) @ 8, 750 rpm
Transmission	6-speed with Ducati Quick Shift (DQS) up/down
Bore x Stroke	83 mm x 53.5 mm
Compression Ratio	14:1
Front Wheel Travel	170 mm (6.7 in)
Rear Wheel Travel	180 mm (7.1 in)
Front Tire	120/70 ZR19
Rear Tire	170/60 ZR17
Wheelbase	1, 567 mm (61.7 in)
Dry Weight	215 kg (474 lb)
Curb Weight	240 kg (529 lb)
Fuel Capacity	22 l (5.8 US gal)
Engine Type	V4 Granturismo, 4-cylinder, liquid-cooled
Fuel Injection	Electronic fuel injection system, Øeq 46 mm throttle bodies
Exhaust	Single stainless steel muffler with catalytic converter and 2 lambda probes
Final Drive	Chain
Frame	Aluminum monocoque
Front Brake	2 x Ø 330 mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	Ø 265 mm disc, 2-piston caliper
Seat Height	Adjustable 840-860 mm (33.1-33.9 in)
Safety Equipment	Cornering ABS, Ducati Traction Control
Standard Equipment	Cruise Control, TFT color display
