Ducati MULTISTRADA V4 User Manual

Annual Service *
Valve Check *
Oil Service *
Oil Service 1000 *
Visual check of the front fork and rear shock absorber seals • • •
Check brake and clutch fluid level • • •
Change brake and clutch fluid 24
Check front and rear brake disk and pad wear. Change if necessary • •
Check the proper tightening of brake calliper bolts and front and rear brake disk screws • •
Check front and rear wheel nuts and rear sprocket nut tightening • •
Check the tightening of frame fasteners to engine, swinging arm and rear shock absorber •
Checking the front and rear wheel hub bearings and the steering tube bearing play • •
Check the silentblocs on rear sprocket and lubricate the rear wheel  •
Check wear of chain, front and rear sprocket, and final drive chain elongation, tension and
lubrication.
Detected elongation value:___________ (cm) (in)
• • •
Check the freedom of movement and tightening of the side stand • • •
239

Ducati MULTISTRADA V4 Specifications

General

Displacement	1, 158 cc
Power	170 hp (125 kW) @ 10, 500 rpm
Torque	125 Nm (92 lb-ft) @ 8, 750 rpm
Transmission	6-speed with Ducati Quick Shift (DQS) up/down
Bore x Stroke	83 mm x 53.5 mm
Compression Ratio	14:1
Front Wheel Travel	170 mm (6.7 in)
Rear Wheel Travel	180 mm (7.1 in)
Front Tire	120/70 ZR19
Rear Tire	170/60 ZR17
Wheelbase	1, 567 mm (61.7 in)
Dry Weight	215 kg (474 lb)
Curb Weight	240 kg (529 lb)
Fuel Capacity	22 l (5.8 US gal)
Engine Type	V4 Granturismo, 4-cylinder, liquid-cooled
Fuel Injection	Electronic fuel injection system, Øeq 46 mm throttle bodies
Exhaust	Single stainless steel muffler with catalytic converter and 2 lambda probes
Final Drive	Chain
Frame	Aluminum monocoque
Front Brake	2 x Ø 330 mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	Ø 265 mm disc, 2-piston caliper
Seat Height	Adjustable 840-860 mm (33.1-33.9 in)
Safety Equipment	Cornering ABS, Ducati Traction Control
Standard Equipment	Cruise Control, TFT color display
