Ducati MULTISTRADA V4 - Page 34

Press the bayonet  (3), turn them clockwise to
tighten them.
 the passenger seat
The passenger seat is adjustable lengthwise.
Slightly move the latch (C) in the indicated direction
(towards the front of the seat) and disengage the pin
(6) of the passenger seat (2) by turning it based on
the desired position:
- A, pin facing the front end, seat forward;
- B, pin facing the rear end, seat backward.
4
3
3
Fig 14
6 C
A
B
Fig 15
33
