Ducati MULTISTRADA V4 User Manual

no. Description Colour
1 Rev limiter / immobilizer Red
2  turn indicator Green
3 MIL
- The warning light turns steady on in case of error in engine management.
Proceed slowly, avoid harsh acceleration and  take the vehicle
to a Ducati authorised service centre to eliminate the malfunction.
- The warning light turns on flashing to warn about a critical emission-re‐
lated error that could damage the catalytic  If possible, have the
vehicle be taken to a Ducati authorised service centre and the malfunc‐
tion eliminated and at any rate proceed slowly, avoid harsh acceleration
and 
Amber yellow
4 High beam on Blue
5 ABS system malfunction
- flashing: ABS in self-diagnosis and/or functioning with degraded per‐

- on: ABS disabled and/or not functioning due to a fault in the ABS control
unit.
Amber yellow
6 VHC Amber yellow
7 Right turn indicator Green
8 Generic error Amber yellow
9 Low fuel Amber yellow
89

Ducati MULTISTRADA V4 Specifications

General

Displacement	1, 158 cc
Power	170 hp (125 kW) @ 10, 500 rpm
Torque	125 Nm (92 lb-ft) @ 8, 750 rpm
Transmission	6-speed with Ducati Quick Shift (DQS) up/down
Bore x Stroke	83 mm x 53.5 mm
Compression Ratio	14:1
Front Wheel Travel	170 mm (6.7 in)
Rear Wheel Travel	180 mm (7.1 in)
Front Tire	120/70 ZR19
Rear Tire	170/60 ZR17
Wheelbase	1, 567 mm (61.7 in)
Dry Weight	215 kg (474 lb)
Curb Weight	240 kg (529 lb)
Fuel Capacity	22 l (5.8 US gal)
Engine Type	V4 Granturismo, 4-cylinder, liquid-cooled
Fuel Injection	Electronic fuel injection system, Øeq 46 mm throttle bodies
Exhaust	Single stainless steel muffler with catalytic converter and 2 lambda probes
Final Drive	Chain
Frame	Aluminum monocoque
Front Brake	2 x Ø 330 mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	Ø 265 mm disc, 2-piston caliper
Seat Height	Adjustable 840-860 mm (33.1-33.9 in)
Safety Equipment	Cornering ABS, Ducati Traction Control
Standard Equipment	Cruise Control, TFT color display
