no. Description
9 Engine Coolant temperature (°C or °F)
The temperature display range goes from +40 °C to +150 °C (+104 °F ÷ +302 °F).
If the temperature is below +40 °C (+104 °F), Low is displayed, whereas if it is above +150 °C (+302 °F),
High is displayed flashing red.
In case of overheating, if possible, it is recommended to ride at reduced speed to allow the
cooling system to lower the engine temperature. If this is not possible due to conditions, stop
and turn the engine
If the motorcycle continues to be used when the engine is overheated, severe damage may occur.
When the engine temperature returns to normal, continue riding by frequently checking the in‐
strument panel indication.
10 Rev counter
Refer to Engine rpm indication (page 100)
11 Air temperature (°C or °F)
Note
When the motorcycle is stopped, the engine heat could influence the displayed temperature.
94
