Note
The level 1 LED brightness of is lower than the
level 2 LED brightness. It is possible to adjust LED
brightness on rear-view mirrors using the Blind Spot
Detection function in the menu (page 225).
General Information
The BSD is available at speeds over 25 km/h (15
mph).
Vehicles approaching or the
motorcycle (1, Fig 109)
The BSD system signals vehicles approaching the
motorcycle or passing it, as long as it detects them
and classifies them as critical. A vehicle can be
identified even if it is still far away. The higher the
approach speed of the vehicle, the sooner the
system will signal its presence. The best signal
accuracy is achieved when the relative speed of the
vehicle approaching the motorcycle is less than 36
km/h (20 mph).
Vehicles travelling to the side of the
motorcycle (2, Fig 109)
A vehicle that travels in the same direction as the
motorcycle, if detected, is signalled by the BSD
Fig 109
136
