Controlling I/O System Outputs
This feature lets you control I/O System outputs connected to external devices such as
lights, bells, or door locks. Output assignments are programmable and can vary, so
contact your system administrator for details.
1. ATEL: Lift the handset or press SPKR PHONE.
STEL, DTMF telephone, or CTEL: Lift the handset.
2. ATEL: Dial 754, enter the desired output activity (see below), enter the I/O output
number (01 through 08), then press #.
0—output off
1—output on
2—output momentarily on for 1 second
STEL, DTMF telephone, or CTEL: Same as ATEL.
3. ATEL: Hang up the handset or press SPKR PHONE.
STEL, DTMF telephone, or CTEL: Hang up the handset.
Controlling OCC System Outputs
This feature lets you control OCC System outputs connected to external devices such as
lights, bells, or door locks. Output assignments are programmable and can vary, so
contact your system administrator for details.
1. ATEL: Lift the handset or press SPKR PHONE.
STEL, DTMF telephone, or CTEL: Lift the handset.
2. ATEL: Dial 764, enter the desired output activity (see below), enter the I/O output
number (e.g., 001, 002), then press #.
0—output off
1—output on
2—output on 1 second
3—output cycles continuously, 1 second on, 1 second off
4—toggle or switch states (e.g., high to low)
STEL, DTMF telephone, or CTEL: Same as ATEL.
3. ATEL: Hang up the handset or press SPKR PHONE.
STEL, DTMF telephone, or CTEL: Hang up the handset.
