2-9
Chapter 2 Basic Operation
Stapling position
Stapling width is the center to center distance between the two staples.
The stapling width and the stapling position are determined by a paper size.
Saddle stapling and folding
The stapling width is 70 mm/2.76 inches, 108 mm/4.25 inches or 160 mm/6.30 inches depending on a
paper size.
Staple
Paper feed direction
Stapling width (70,108, or 160 mm
/2.76, 4.25, or 6.30 inches)
Paper width
Side stapling
Staples between 5.5 mm/0.22 inch and 6.5 mm/0.26 inch from the lead edge of the paper.
The stapling width is 108 mm/4.25 inches or 160 mm/6.30 inches depending on a paper size.
Stapling width (108 or 160 mm
/4.25 or 6.30 inches)
5.5 to 6.5 mm/0.22 to 0.26 inch
Staple
Paper feed direction
Paper width
Corner stapling
Staples between 5.5 mm/0.22 inch and 6.5 mm/0.26 inch from the lead edge of the paper.
The stapling position is 129 mm/5.08 inches or 138 mm/5.43 inches depending on a paper size.
Stapling position (129 or 138 mm/
5.08 or 5.43 inches)
Staple when[Corner F]
is selected
5.5 to 6.5 mm/0.22 to 0.26 inch
Paper feed direction
Paper width
Staple when[Corner B]
is selected
To Next Page
