38
10. SPECIFICATIONS
Name
Model
No. of tables
Paper feeding method
Paper carrying method
Paper feed table capacity
Paper sizes
Paper quality
Paper type
Collating speed
Paper receiving table capacity
Paper feed table detection
Paper feed error detection
Other detections
Error display
Counter
Additional functions
Power supply
Power consumption
Size
Mass (Weight)
Specifications and external dimensions may be changed, without prior notice, to
upgrade the unit.
DC-10 mini
Desktop
10
3-rings paper separator
Roller belt
28 mm (Fine quality paper:64g/m
2
, equivalent to 280 sheets)
Smallest:A5 (148x210)
Largest:A3SR (320x450)
But the smallest paper (A5) can only be fed horizontally and the largest paper
(A3SR) be collated in the NORMAL mode. The SORT mode can be carried
out only for size A3 (297x420) and smaller.
Medium quality paper, fine stencil paper, fine quality paper (52.3 to 128 g/m
2
)
Sheet
35 sets/min. or 55 sets/min.
But it depends on the specifications of the downstream processing device if it
is used.
55 mm (Fine quality paper:64 g/m
2
, equivalent to 550 sheets)
The PRESET key is used to distinguish the paper feed tables used
No-feeding, multi-feeding, paper jamming
No-paper detection, door open detection, paper receiving table full detection,
downstream processing device error detection
Displayed on the control panel
Carrier cover open/close, Tower B error (when towers are linked), Tower A error
(when towers are linked), downstream processing device error, paper receiving
table full, No paper on tables, no-feeding, multi-feeding, paper jamming
4-digit adding counter, 4-digit subtracting counter
• Forcible ejection function
• Selection of NORMAL mode/SORT mode (Paper sorted by left/right
swing)
• Selection of SINGLE, CONTINUOUS, INTERLEAVING modes
• Collating speed can be changed in two levels
AC230V/50Hz
1.5A
When used:790 (W) x 500 (D) x 970 (H) mm (including the stabilizer)
66 kg
