4
Table of Contents
1. WARNINGS .................................... 5
2. PRECAUTIONS.............................. 8
2-1. Precautions in Installation ........................ 8
2-2. Component Parts ..................................... 9
2-3. Attaching the Parts ................................ 10
3. NAMES OF EACH PART .................. 12
4 NAMES AND FUNCTIONS OF
CONTROL PANEL PARTS ............... 13
5. PRECAUTIONS BEFORE USE......... 16
5-1. Stacking the Paper ................................ 16
5-2. Stacking According to Paper Size ......... 17
5-3. Stacking Paper for the SINGLE Mode ... 17
5-4. Stacking Paper for
the CONTINUOUS Mode....................... 18
5-5. Stacking Paper for
the INTERLEAVING Mode .................... 18
6. OPERATING PROCEDURES ........... 19
6-1. Procedures for Using the Unit................ 19
6-2. PRESET Key ......................................... 26
6-3. SORT Mode and NORMAL Mode ......... 27
6-4. SINGLE, CONTINUOUS,
and INTERLEAVING Modes.................. 28
6-5. Dip Switches .......................................... 30
7. WHAT TO DO WHEN ........................ 31
7-1. When the PAPER FEED TABLE ERROR
Lamp Lights Up in Green ....................... 31
7-2. When the PAPER FEED TABLE ERROR
Lamp Blinks in Green ............................ 31
7-3. When the PAPER FEED TABLE ERROR
Lamp Lights Up in Red .......................... 31
7-4. When the PAPER FEED TABLE ERROR
Lamp Blinks in Red ................................ 32
7-5. When the PAPER FEED TABLE ERROR
Lamp Blinks Quickly in Red ...................32
7-6. When the CARRIER COVER OPEN
Lamp Lights Up...................................... 33
7-7. When the PAPER FULL
Lamp Lights Up...................................... 33
7-8. When the PERIPHERALS
Lamp Lights Up...................................... 33
7-9. When the PERIPHERALS
Lamp Blinks ........................................... 33
7-10. When the Paper Jams ........................... 34
8. TROUBLESHOOTING GUIDE .......... 35
8-1. When the Unit does not Start Even When
the START/STOP Key is Pressed ......... 35
8-2. When the PAPER JAM ERROR Lamp
Lights Up Although the Paper is Being
Fed Properly .......................................... 35
8-3. When No-Feeding Occurs Frequently ... 35
8-4. When Multi-Feeding Occurs
Frequently .............................................. 35
8-5. When “E-1” is Displayed on
the NO. OF SETS Window .................... 36
8-6. When “E-2” is Displayed on the
NO. OF SETS Window .......................... 36
8-7. When “E-5” is Displayed on the
NO. OF SETS Window .......................... 36
9. DAILY CLEANING AND REPLACING
EXPENDABLE PARTS ..................... 37
10.SPECIFICATIONS ............................. 38
