26
6. OPERATING PROCEDURES
6-2. PRESET KEY
Use the PRESET key to check which table has paper and which does not, and at the
same time, to record the thickness of the paper. After checking, the paper will be fed
only from the table which has paper.
ó
When the PRESET key is pressed, paper will be
fed from the paper feed table for one set.
ò
Hold the set of paper ejected and check that the
paper has been fed properly. If it has, press the
START/STOP key and start operations.
• If there is no paper on all the paper feed tables, the
error lamps of all tables will light up in green.
• In the first operation, the NO. OF SETS window
will display 1.
After the operation, the window will display the
number it had displayed previously+1.
If the subtract display method is used and the
number of sets required is input first and then
the preset key is pressed, the window will
display the “number input”–1.
ô
When problems occur such as no-feeding, paper
jams, etc. check the cause.
ö
When multi-feeding occurs, check the cause.
After correcting it, press the CLEAR key and
return the NO. OF SETS window to 0.
Note
Multi-feeding detection cannot be carried out for some
types of paper. In such cases, the PAPER FEED
TABLE ERROR lamp will blink quickly in red.
Cancel the detection function using the dip switch.
Refer to ''6-5. Dip Switches" on page 30.
õ
Press the PRESET key again.
• Check that the paper is fed properly.
Note
If the table used has been changed or the paper used
has been replaced, be sure to press the PRESET key.
Paper
To Next Page
