16
• If the sheets of paper have not been folded
satisfactorily, refer to the following steps.
1 If there is folding slippage in the vertical direction,
rotate the fine adjustment knob and correct the
folding slippage.
Refer to “8-1. Adjusting the folding slippage in the
vertical direction”.
2 If the folding has slipped in the horizontal
direction:
Rotate the “slant correction knob” and adjust the
folding slippage.
Refer to “8-2. Adjusting the folding slippage in the
horizontal direction”.
Check the folding slippage in the horizontal
direction with the second sheet of test fold
sample.
9 After completing all preparations,
start operation.
• Press the start button.
10 The unit stops automatically when
there is no more paper on the paper
feed table.
7. OPERATION PROCEDURES
Fine adjustment knobFine adjustment knob
Second folding plate First folding plate
Slant correction knob
To Next Page
