28
6 Press the start button to test the
folding.
• Check that the paper has been folded properly.
Check the second piece of paper folded first.
• If the sheets of paper have not been folded
satisfactorily, refer to the following steps.
1 If there is folding slippage in the vertical direction,
rotate the fine adjustment knob and correct the
folding slippage.
Refer to “8-1. Adjusting the folding slippage in the
vertical direction”.
2 If the folding has slipped in the horizontal
direction:
Rotate the “slant correction knob” and adjust the
folding slippage.
Refer to “8-2. Adjusting the folding slippage in the
horizontal direction”.
Check the folding slippage in the horizontal
direction with the second sheet of test fold
sample.
7. OPERATION PROCEDURES
Paper for testing folding
Fine adjustment knob
<Second folding plate>
Fine adjustment knob
<First folding plate>
Slant correction knob
