36
14. WHEN BIN ERROR LAMPS LIGHT/BLINK
When paper feed errors occur during op-
erations, the warning alarm sounds, and
the bin error lamps on the control panel
light up or blink.
Refer to the solutions provided below and
clear the error.
Note When “Err1” is displayed on the NO. OF SETS
window, remove the last set ejected. When
“Err2” is displayed remove the last two sets.
The last or the last two sets may be incom-
plete.
14-1. When an error lamp lights in green
14-2. When an error lamp lights in red
Paper has run out in the bin.
• Replenish paper in the bin.
After replenishing, press the Start key to
restart operations.
The lamp also lights up when there is no
paper in the bin during preset settings.
• Remove the jammed paper.
After removing, press the Start key to re-
start operations.
Error lamp Cause of error
Paper
Paper
Paper has jammed in the bin.
To Next Page
