Duplo DFC-12 - 15 When Error Messages Are Displayed; When No Paper Is Displayed; When Tray Full Is Displayed

38
15. WHEN ERROR MESSAGES ARE DISPLAYED
When errors occur, a warning alarm sounds, and an error message will be displayed on the
LCD.
15-1. When "No Paper" is displayed
15-2. When "Tray Full" is displayed
There is no more paper in the bin.
• Load paper in the bin where the error
lamp is lit in green.
• Check that the paper sensor lever de-
scends when paper is stacked.
Press the Start key to restart operations.
The paper receiving table is full.
• Remove the paper on the paper re-
ceiving table.
1 Pull the stopper 1 to the front.
2 Remove the paper, and return stop-
per 1 to the original position.
Press the Start key to restart operations.
• Check that the full detection sensor
lever does not remain raised.
Paper sensor
Paper
Paper
Full detection sensor
