Duplo DFC-12 - When Feed Error Is Displayed; When Preset Error Is Displayed

39
15. WHEN ERROR MESSAGES ARE DISPLAYED
15-3. When "Feed error" is displayed
15-4. When "Preset Error" is displayed
Paper has jammed at the double-feed sensor or paper feed gate.
Check the bin where the error lamp is lit in red.
• When paper has jammed at the paper feed ring
Pull out the jammed paper to the front, and remove.
• When paper has jammed at the double-feed sensor
Open the conveyance cover, and remove the jammed paper.
Press the Start key to restart operations.
• The Start key is pressed without press-
ing the Preset key.
• The Start key is pressed immediately af-
ter changing the collation mode.
Press the Preset key first.
Paper feed ring
Paper
Paper
3
6
9
