43
15.
WHEN ERROR MESSA
GES ARE DISPLA
YED
15-11.
When
“
On-line err" is displayed
An error has occurred in the downstream unit.
•
Check the error on the control panel of the do
wnstream unit.
For details on clearing the error
, refer to the instruction manual of the do
wnstream unit.
Press the Star
t k
ey to restart operations.
44
