Duplo DFC-12 User Manual

51
19. CLEANING THE UNIT AND REPLACING EXPENDABLE PARTS
Cleaning the unit
Ink or paper dust adheres to the paper feed ring or paper separator which feeds paper. Running the unit
in this state will cause paper feed problems. Therefore clean periodically.
1
Press the paper feed shaft in the ar-
row direction, and remove the end
of the paper feed shaft at the joint.
Remove the paper feed shaft.
2
At places which are dirty with ink or
paper dust, wipe off with a cloth
moistened with neutral detergent or
alcohol.
3
Also clean the paper separator of the
bins whose paper feed shaft re-
moved.
Clean after removing the paper feed shaft.
Replacing Expendable Parts
If the paper feed ring or paper separator has worn out, request replacement of parts to your nearest
Duplo dealer.
Paper feed shaft
Joint
Paper feed ring
Paper separator
Paper feed shaft
Joint
