Duplo DUPRINTER DP-440 - Page 237

239
c HELP Mode Function and Operation Procedures
chap.7
H-17
(1) Adjustment / specification settingHELP mode
ABCD Item Setting
0***
Disable
1***
*0**
Used
*1**
Not used
No rotation
90 degrees
**00
180 degrees
**01
AUTO
**10
Editing setting
**11
0000
Factory setting
Pre-platemaking slider
operation enable/disable
Thick paper feed setting
Enable
ePress the [=] key.
The correction amount will be memorized in the battery PCB unit's
EEPROM. During memorization,"SAVE" will be displayed.
Do not turn off the power before the "SAVE" display has disappeared.
1. Functions
(1) Pre-platemaking slider operation enable/disable / Thick
paper feed setting / Editing setting
¡Following items are indicated.
A : Pre-platemaking slider operation enable/disable
B : Thick paper feed setting
C,D : Editing setting
(1) Pre-platemaking slider operation enable/disable / Thick
paper feed setting / Editing setting
¡During memorization:
IMPORTANT :
2. Operation procedure
Accessing HELP modes
a See page 213
qAccess HELP mode H-17, and press the PRINT key.
HELP-017
Spec setting
1111
wUse the [0] and [1] numeric keys to enter a 4-place binary
value for the desired correction amount.
See the table below for 4-place binary values and the corresponding
correction amounts.
a To exit the HELP mode : Turn the power switch OFF.
a To access another HELP mode : Enter the desired mode number
using the numeric keys.
rPress the STOP key.
The HELP mode selection display will reappear.
A B C D
- SAVE -
