54
x Platemaking / Master Feed / Ejection Section
chap.2
When the drum stops at the plate detachment position and the master clump which clumps the master tip
end is opened (C mode), the pulling roller on the rolling section of the master ejection box pulls the master tip
end into the box inside, and the master is rolled up to the core.
If no core is installed, or when the master is fully wound onto the core, the core full switch (MS8) is
mechanically actuated, and the message "CHANGE MASTER EJECTION CORE" appears on the LCD panel.
To Next Page
