Duplo DUPRINTER DP-440 - Connector VR;LED Layout and Functions

303
z Electrical Parts Layout and Their Functions
chap.8
(6) Connector VR/LED Layout and Functions
1) CCD PCB unit (N5-V320
**
)
2) Inverter PCB unit (J2-X105
**
)
3) LCD Panel (TG014
**
)
CCD
CN1
CN 2
CN 1
440910
440917
440904
¡ Do not remove the CDD PCB or loosen the screw
in the market.
IMPORTANT :
