z Electrical Parts Layout and Their Functions
chap.8
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
z Electrical Parts Layout and Their Functions
(1) Switches/Clutches/Solenoids
440911
Option
Drum rotation
Drum rotation
Paper feed elevator descent
Master cut
Master cover open/closed detection
Front cover open/closed detection
Elevator bottom limit
Whether the drum is set or not is detected.
Whether the master ejection core is set or not and full or not is detected.
Scanner open/closed detection
Contact pressure position is detected.
Contact pressure limit
Power ON/OFF
Master feed clutch
Paper feed solenoid
Tape cluster solenoid
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
FunctionsItem
Microswitch/switch
Push switch
Solenoid
Clutch
No.
