267
c HELP Mode Function and Operation Procedures
chap.7
H-47
(1) Adjustment / specification settingHELP mode
ePress the [=] key.
The correction amount will be memorized in the battery PCB unit's
EEPROM. During memorization,"SAVE" will be displayed.
Do not turn off the power before the "SAVE" display has disappeared.
1. Functions
(1)
Setting of special paper size width (lower-order 4bits)
¡
The width of a special paper size is set using HELP modes H-47
and H-48.
H-47 is used for the lower-order 4 bits of the setting,
and H-48 for the higher-order 4.
(1)
Setting of special paper size width (lower-order 4bits)
¡During memorization:
IMPORTANT :
2. Operation procedure
Accessing HELP modes
a
See page 213
qAccess HELP mode H-47, and press the PRINT key.
wUse the [0] and [1] numeric keys to enter a 4-place binary
value for the desired correction amount.
See the table below for 4-place binary values and the corresponding
correction amounts.
a
To exit the HELP mode
: Turn the power switch OFF.
a
To access another HELP mode
:
Enter the desired mode number
using the numeric keys.
rPress the STOP key.
The HELP mode selection display will reappear.
A B C D
- SAVE -
Set width(mm)H-47H-48
0000 0000
Initial value
0000 0001
Set width
Converted desimal value for binary H-48 (upper 4
bits) + binary H-47 (lower 4 bits)
9
2 mm
Example : H-46 = 0111, H-45 = 1101
01111101 = 125
125
9
2 = 250
Set width = 250mm
Maximum value is 290mm.*
0000 0010
·····
·····
1001 0001
Maximum : 290mm
To Next Page
