DuraLabel PRO 300 - Printer Ribbon Parts

DuraLabel.com | 800.788.5572 2.2 Printer Ribbon Parts | 7
LOADING THE PRINTER
2.2 Printer Ribbon Parts
Rear Spring-Loaded Hub
for Ribbon Supply Spindle
Rear Hub for Flange Side of
Ribbon Supply Spindle
Front Hub for Flange Side of
Ribbon Rewind Spindle
Front Spring-Loaded Hub
for Ribbon Rewind Spindle
(with paper core)
Lo
L
ade
dHub
fo
rF
lan
ge
Figure 1
NOTE:6SLQGOHÁDQJHVVKRXOGEHLQVHUWHGRQULJKWVLGHZKHQIDFLQJSULQWHU6HH
diagram under the ribbon supply.
Ribbon Spindle Flange
Ribbon Rewind Spindle
with Paper Core Applied
Ribbon Supply Spindle
Figure 2
