Performance description
Operating manual 281 Version 06.0 - 05/201310
3.4 Technical data
Noise emission
Workplace-specific emission value as per DIN EN ISO 10821:
281-140342: LC = 78 dB (A) ± 0.96 dB (A)
At: Stitch length: 3.2 mm
Number of stitches: 4400 min
-1
Material to be sewn: 2-layer material
G1 DIN 23328
Features
281-
140342-02
281-
160362-02
281-
140342-01 A
Sewing stitch type Double lockstitch 301
Hook type Horizontal hook, small
Oiling oiled
Number of needles 1
Needle system 134 134 DBx1
Needle bar piston dimension [mm] 2.0 2.0 1.62
Max. needle strength [Nm] 65 –100 90 – 130 #9 – #16
Max. sewing thread size 50/3 30/3 50/3
Max. stitch length, forwards/backwards [mm] 4.5 6 4.5
Max. number of stitches [rpm] 5000 4000 5000
Number of stitches on delivery [rpm] 4800 4000 4800
Max. sewing foot stroke (lifting with knee lever)
[mm]
14.5 16 14.5
Max. sewing foot stroke (lifting with magnet)
[mm]
12
Sewing foot stroke on delivery 9
Rated voltage [V/Hz] 200 – 240 V
50/60 Hz
Rated voltage on delivery [V/Hz] 1x230 V
50/60 Hz
Rated power [kVA] 0.5
Length/width/height [mm] 540/430/215
Pack size incl. upper part, accessory pack,
and controller (length/width/height) [mm]
785/694/300
Total weight (incl. packaging) [kg] 54.5
