Operation
Operating manual 281 Version 06.0 - 05/2013 25
5.5 Setting the bobbin filling quantity
Figure 9: Setting the bobbin filling quantity
1. Loosen the screw (1).
2. Set the metallic bobbin winder piece (2):
• Lower filling quantity:
Pivot the metallic bobbin winder piece (2) towards the
bobbin.
• Larger filling quantity:
Pivot the metallic bobbin winder piece (2) away from the
bobbin.
3. Tighten the screw (1).
Risk of injury from moving parts.
Switch off the sewing machine before setting the
bobbin filling quantity.
WARNING
(1) - Screw (2) - Metallic bobbin winder
②
①
