Operation
Operating manual 281 Version 06.0 - 05/201326
5.6 Replacing the hook thread bobbin
Figure 10: Replacing the hook thread bobbin
1. Raise the spool housing flap (2).
2. Remove the spool housing upper section (1) together with the
bobbin (3).
3. Remove the empty bobbin.
4. Insert a full bobbin.
Important: Insert the bobbin (3) such that it moves in the
direction of the arrow when pulling off the thread.
5. Guide the hook thread through the slot underneath the
tensioning spring (4) and into the hole (5).
6. Pull the hook thread approx. 5 cm out of the spool housing
upper section (1).
7. Insert the spool housing upper section (1) with the full bobbin.
8. Close the spool housing flap (2).
Risk of injury from moving parts.
Switch off the sewing machine before replacing the
hook thread bobbin.
WARNING
(1) - Spool housing upper section
(2) - Spool housing flap
(3) - Bobbin
(4) - Tensioning spring
(5) - Hole
①
②
③
④
⑤
