7 Set-up
7.1 Checking the scope of delivery
Important: The scope of delivery depends on your specific order.
1. Prior to set-up, check that all parts are present.
Figure 29: Example of scope of delivery when all components are
delivered complete
Risk of injury.
The machine may only be set up by trained
specialists.
Wear safety gloves and safety shoes when
unpacking and setting up.
WARNING
(1) - Control panel
(2) - Upper part of machine
(3) - Table plate
(4) - Drawer
(5) - Frame
(6) - Pedal
(7) - Rod
(8) - Oil pan
(9) - Controller
(10) - Thread stand
