Device description
Operating manual 281 Version 06.0 - 05/2013 15
4 Device description
Figure 1: Complete overview
(1) - Control panel
(2) - Preliminary tensioner
(3) - Thread regulator
(4) - Main tensioner
(5) - Needle bar
(6) - Pushbutton on the machine arm
(7) - Adjusting wheel for the sewing foot pressure
(8) - Stitch adjustment lever
(9) - Adjusting wheel for the stitch length
(10) - Handwheel
(11) - Bobbin
