DURKOPP ADLER 281 - Pushbutton on the Machine Arm

Operation
Operating manual 281 Version 06.0 - 05/201338
5.13 Pushbutton on the machine arm
The machine is equipped with a pushbutton (1) on the machine
arm by default.
Figure 22: Pushbutton on the machine arm
It can be used to switch on various functions depending on the
setting on the control panel ( Section 5.14 Operating the
controller, page 39):
• Bartack sewing
• Raising the needle
• Bartack suppression
A multi-function pushbutton is available as additional equipment:
Figure 23: Additional equipment: multi-function pushbutton
The buttons can be used to perform the following functions:
• Button (2): Switching the sewing lamp on/off
• Button (3): Activate / deactivate the bartack suppression
• Button (4): Half stitch, positioning the needle up/down
• Button (5): Manual bartack
(1) - Pushbutton on the machine arm
①
Keys for:
(2) - Sewing lamp
(3) - Bartack suppression
(4) - Half stitch/needle position
(5) - Manual bartack
②
③
④
⑤
