Operation
Operating manual 281 Version 06.0 - 05/2013 19
Figure 3: Inserting and replacing the needle
1. Turn the handwheel until the needle bar (1) reaches the upper
end position.
2. Loosen the fastening screw (2).
3. Pull the needle out towards the bottom.
4. Insert the new needle.
5. Important: Align the needle so that the groove (4) faces the
hook (3).
6. Tighten the fastening screw (2).
(1) - Needle bar
(2) - Fastening screw
(3) - Hook
(4) - Groove
