Maintenance
Operating manual 281 Version 06.0 - 05/201346
Figure 26: Points that need to be cleaned particularly thoroughly
Areas particularly susceptible to soiling:
• Area under the needle plate (1)
• Spool housing and inner area (3)
• Hook (4)
• Motor fan filter (2)
Cleaning steps:
1. Switch off the power supply at the main switch.
2. Remove any sewing dust and thread remains using a
compressed-air pistol or a brush.
(1) - Area under the needle plate
(2) - Motor fan filter
(3) - Spool housing
(4) - Hook
①
②
③
④
Possible damage to the paintwork from solvent-based
cleaners.
Solvent-based cleaners damage the paintwork of the
machine.
Only use solvent-free substances for wiping the machine.
ATTENTION
