3.3 Setting the working height
–
The working height is adjustable between 750 and 900 mm
(measured to the upper edge of the table plate).
–
Undo screws 4 on the stand braces.
–
Adjust the table plate horizontally to the required working height.
To prevent tilting, pull the table plate out or push it in by the same
distance on both s ides.
–
Tighten both screws 4.
4. Sewing drives
4.1 Drive category, type and use
The following sewing drives are available:
Drive type Clutch motor Clutch DC
positioning drive positioning drive
Type 1147-F.752.3 *
1148.552.3
VD552KV/6F82FA DC1600/DA82GA
Use 367-170010
367-180010
367-170010
367-180010
367-170010; -180010
367-170115; -180115
367-170315; -180315
* This clutch motor incorporates an electromagnetic brake that rapidly
stops the rotor when it runs on after the motor has been switched off.
This prevents the sewing machine from starting up unintentionally if
the pedal is operated shortly after switching off.
4.2 Fitting the sewing drive
–
Attach the sewing drive 5 with its base 6 on the underside of the
table plate.
By screwing the three hexagonal screws 3 (M8x35) with washers 2
into the table-plate nuts 1.
9
