1. Scope of Delivery
What items are supplied depends on your order .
Prior to setting up, please check that all the required parts are present.
Equipment (depending on the subclass):
1 Sewing lamp
2 Machine head
3 Table plate
4Drawer
5 Stand
6 Yarn stand
7 Proximity switch
8 Belt guard
9 Operating panel
10 Main switch
11 Knee lever
12 Sewing drive
13 Maintenance unit
14 Pedal linkage
15 Pedal
16 Belt pulley and V-belt
17 Small parts in the accessory pack
2. General and transport packing
Caution:
The special sewing machine must be set up by trained specialist
personnel.
If the special sewing machine you have bought is already set up, the
following transport packing must be removed:
–
Safety straps and battens on the machine head, table and stand
–
Safety block and straps on the sewing drive
5
